LevelOne RJ45 To SFP Gigabit Media Converter Switch GVT-2011
The LevelOne GVT-2011 Gigabit Media Converter Switch provides 1 RJ45 and 2 SFP ports to support conversion between 10/100/1000Base-T and 1000Base-X networks. With the two SFP ports, the converter switch provides high reliability and flexibility to extend the media transmission distance up to 550m, 20km, or longer depending on the SFP fiber optical transceivers. It allows the two types of segment to connect easily, efficiently and inexpensively.
General:
2 ports 1000Base-SX/LX SFP Fiber optic, 1 port 10/100/1000Base-T RJ45
Auto-Negotiation for 10/100 Base-TX Full-Duplex and 10/100 Base-TX Half-Duplex
Support IEEE 802.3x Full-Duplex Flow-Control and Back pressure for Half-Duplex to eliminates packets loss
Support Auto MDI/MDI-X function
Support VLAN tag, Multicast pass through, and support the max packet length 9000 bytes
Store-and-Forward mechanism, and 3-port data auto-switching or Backup mode for fiber ports
Standards & Protocols:
IEEE802.3 10Base-T Ethernet
IEEE802.3u 100Base-TX Fast Ethernet
IEEE802.3ab 1000Base-T
IEEE802.3z 1000Base-X Gigabit Ethernet over Fiber-Optic
IEEE802.3x flow control
Port:
2 x SFP Slot
1 x RJ45
1 x DC Jack
Indicator: PWR, 1000M, LINK/ACT, F1, F2
Wavelength (nm): depend on SFP fiber optical transceiver
Transmission Method: store and Forward mechanism
Power Input: 110VAC~240VAC
Power Output: 5V/2A
Power Consumption: MAX to 5w
Operating Temperature (°C): -10~55ºC
Operating Humidity (Non-condensing): 5% ~ 90% non-condensing
Mount: wall, desktop, chassis
LevelOne RJ45 To SFP Gigabit Media Converter Switch GVT-2011
The LevelOne GVT-2011 Gigabit Media Converter Switch provides 1 RJ45 and 2 SFP ports to support conversion between 10/100/1000Base-T and 1000Base-X networks. With the two SFP ports, the converter switch provides high reliability and flexibility to extend the media transmission distance up to 550m, 20km, or longer depending on the SFP fiber optical transceivers. It allows the two types of segment to connect easily, efficiently and inexpensively.
The GVT-2011 works in high performance Store and Forward mechanism, and prevent packet loss with IEEE 802.3x Flow Control (Full-Duplex) and Back Pressure (Half-Duplex) functions. As the GVT-2011 Media Converter fully complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T and IEEE 802.3z 1000Base-X, the Gigabit media converter installation is quite quick and easy by simply plug and play.
General:
2 ports 1000Base-SX/LX SFP Fiber optic, 1 port 10/100/1000Base-T RJ45
Auto-Negotiation for 10/100 Base-TX Full-Duplex and 10/100 Base-TX Half-Duplex
Support IEEE 802.3x Full-Duplex Flow-Control and Back pressure for Half-Duplex to eliminates packets loss
Support Auto MDI/MDI-X function
Support VLAN tag, Multicast pass through, and support the max packet length 9000 bytes
Store-and-Forward mechanism, and 3-port data auto-switching or Backup mode for fiber ports
Standards & Protocols:
IEEE802.3 10Base-T Ethernet
IEEE802.3u 100Base-TX Fast Ethernet
IEEE802.3ab 1000Base-T
IEEE802.3z 1000Base-X Gigabit Ethernet over Fiber-Optic
IEEE802.3x flow control
Port:
2 x SFP Slot
1 x RJ45
1 x DC Jack
Indicator: PWR, 1000M, LINK/ACT, F1, F2
Wavelength (nm): depend on SFP fiber optical transceiver
Transmission Method: store and Forward mechanism
Power Input: 110VAC~240VAC
Power Output: 5V/2A
Power Consumption: MAX to 5w
Operating Temperature (°C): -10~55ºC
Operating Humidity (Non-condensing): 5% ~ 90% non-condensing
Mount: wall, desktop, chassis
