Toote kirjeldus inglise keeles:
Noise is an annoying side effect that is caused not only at the airport by aircraft taking off and in traffic by passing trucks. Especially in your own home, therefore, many people strive to provide peace, to find relaxation. Unfortunately, the PC is in many cases contrary to these efforts and annoying during operation with high noise.
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Vault housing from Kolink both approaches are connected and the design tower is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats, additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
When delivered, the Vault has been fitted with insulating mats at all mandatory locations to reduce component noise. This includes the side panel and the entire floor (3-part). The mat for the lid and the front were clamped, but can be glued if necessary. Another mat is loosely in the housing. This is also tailored to fit and can be installed as needed.
All additional insulation mats are labeled, which together with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Kolink Vault and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate. In addition, the built-in fans should be throttled with the built-in control.
Technical details:
Noise is an annoying side effect that is caused not only at the airport by aircraft taking off and in traffic by passing trucks. Especially in your own home, therefore, many people strive to provide peace, to find relaxation. Unfortunately, the PC is in many cases contrary to these efforts and annoying during operation with high noise.
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Vault housing from Kolink both approaches are connected and the design tower is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats, additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
When delivered, the Vault has been fitted with insulating mats at all mandatory locations to reduce component noise. This includes the side panel and the entire floor (3-part). The mat for the lid and the front were clamped, but can be glued if necessary. Another mat is loosely in the housing. This is also tailored to fit and can be installed as needed.
All additional insulation mats are labeled, which together with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Kolink Vault and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate. In addition, the built-in fans should be throttled with the built-in control.
Technical details:
- Dimensions: 200 x 526 x 490 mm (W x H x D)
- Weight: about 7 kg
- Material: steel, plastic
- Color: Black
- Form factor: E-ATX, ATX, Micro-ATX
Total possible fan: 2x 140/120 mm (front)
2x 140/120 mm (cover)
1x 120 mm (back) - Pre-installed:
2x 120 mm (front, blue LED)
1x 120 mm (back, blue LED) - Radiator mountings (partial waiver of HDD and / or fan slots):
1x max. 280/240 mm (front)
1x max. 280/240 mm (cover)
1x max. 120 mm (back) - Drive bays:
2x 5.25 inches (external)
3x 2.5 inches (internal)
2x 3.5 inches (internal) - Power supply: 1x standard ATX (optional)
- Expansion Slots: 7
- I / O Panel:
1x Card Reader (SD, SF)
1x USB 3.0
2x USB 2.0
2x Audio - Maximum graphics card length: 400 mm
- Maximum CPU cooler height: 165 mm
- Maximum power supply length: 180 mm
- Insulation (pre-installed):
Left side panel
Floor (3-piece)
Front side (clamped)
Rear panel (2-piece)
Lid (clamped) - Insulation (enclosed):
Upper back
