Tootekirjeldus inglise keeles:
Noise is an annoying side effect that is caused not only at the airport by aircraft taking off and in traffic by passing trucks. Especially in your own home, therefore, many people strive to provide peace, to find relaxation. Unfortunately, the PC is in many cases contrary to these efforts and annoying during operation with high noise.
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Kolink Sanctuary both approaches are connected and the housing is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats, additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
When delivered, the Kolink Sanctuary has been fitted with insulating mats at all mandatory locations to reduce the noise level of the components. These include the left side panel, the right side panel, the bottom, the lid and the bottom front. Three more mats are loosely in the housing. These are also tailored to fit and can be installed as needed. They are intended for the upper front as well as the back.
All additional insulation mats are labeled, which in conjunction with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Kolink Sanctuary and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate. In addition, the built-in fans should be throttled with the built-in control.
Note:Please note that due to the insulating mats, the space inside the housing may be smaller. Under certain circumstances, the laying of cables behind the mainboard tray can only be limited in comparison to the uninsulated version.
Technical details:
Noise is an annoying side effect that is caused not only at the airport by aircraft taking off and in traffic by passing trucks. Especially in your own home, therefore, many people strive to provide peace, to find relaxation. Unfortunately, the PC is in many cases contrary to these efforts and annoying during operation with high noise.
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Kolink Sanctuary both approaches are connected and the housing is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats, additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
When delivered, the Kolink Sanctuary has been fitted with insulating mats at all mandatory locations to reduce the noise level of the components. These include the left side panel, the right side panel, the bottom, the lid and the bottom front. Three more mats are loosely in the housing. These are also tailored to fit and can be installed as needed. They are intended for the upper front as well as the back.
All additional insulation mats are labeled, which in conjunction with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Kolink Sanctuary and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate. In addition, the built-in fans should be throttled with the built-in control.
Note:Please note that due to the insulating mats, the space inside the housing may be smaller. Under certain circumstances, the laying of cables behind the mainboard tray can only be limited in comparison to the uninsulated version.
Technical details:
- Kolink Sanctuary Micro-ATX-Cube, black Window - insulated
- Dimensions: 265 x 345 x 330 mm (W x H x D)
- Material: steel, plastic
- Color: Black
- Form factor: Micro ATX
- Total possible fan:
2x 120 mm (front)
1x 120 mm (rear)
2x 120 mm (top) - Pre-installed:
1x 120 mm (rear, blue LED)
2x 120 mm (front, blue LED) - Drive bays:
2x 2.5 / 3.5 inches
2x 2.5 inches - Power supply: 1x standard ATX (optional)
- Expansion Slots: 4
- I / O panel:
1x USB 3.0
2x USB 2.0
1x per Audio In / Out
1x fan controller (3-pin, 2x 2 ports) - Maximum graphics card length: 325 mm
- Maximum CPU cooler height: 170 mm
- Maximum network part length: 170 mm
- Insulation (glued):
1x side panel (left)
1x side panel (right)
2x floor (front / rear) - Insulation (clamped):
1x front (bottom)
1x cover - Insulation (included):
1x front side (top)
2x rear side
