Toote informatsioon
Tootekirjeldus inglise keeles:
Noise is an annoying side effect that is caused not only at the airport by aircraft taking off and in traffic by passing trucks. Especially in your own home, therefore, many people strive to provide peace, to find relaxation. Unfortunately, the PC is in many cases contrary to these efforts and annoying during operation with high noise.
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Silverstone SST-FT03S both approaches are connected and the housing is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats, additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
When delivered, the Silverstone SST-FT03S has seven insulation mats already glued. Another mat is clamped, therefore holds in the appropriate position and fulfills its Dämmauftrag, but can also be glued independently when needed. In addition, two mats are loosely in the housing, which are self-assembled as needed.
These mats are not installed so as not to restrict the ventilation of the system. Thus, an individual optimum of insulation (volume reduction) and ventilation (cooling) can be achieved. About the exact positions of the pre-glued, clamped or just enclosed mats give the specifications below information.
All additional insulation mats are labeled, which in conjunction with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Silverstone SST-FT03S and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate. In addition, the built-in fans should be throttled with the built-in control.
Note: Please note that due to the insulating mats, the space inside the housing may be smaller. Under certain circumstances, the laying of cables behind the mainboard tray in comparison to the uninsulated version can only be limited.
Technical details:
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Silverstone SST-FT03S both approaches are connected and the housing is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats, additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
When delivered, the Silverstone SST-FT03S has seven insulation mats already glued. Another mat is clamped, therefore holds in the appropriate position and fulfills its Dämmauftrag, but can also be glued independently when needed. In addition, two mats are loosely in the housing, which are self-assembled as needed.
These mats are not installed so as not to restrict the ventilation of the system. Thus, an individual optimum of insulation (volume reduction) and ventilation (cooling) can be achieved. About the exact positions of the pre-glued, clamped or just enclosed mats give the specifications below information.
All additional insulation mats are labeled, which in conjunction with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Silverstone SST-FT03S and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate. In addition, the built-in fans should be throttled with the built-in control.
Note: Please note that due to the insulating mats, the space inside the housing may be smaller. Under certain circumstances, the laying of cables behind the mainboard tray in comparison to the uninsulated version can only be limited.
Technical details:
- Dimensions: 235 x 487 x 284 mm (W x H x D)
- Material: aluminum (2.5 mm, outsides), steel (skeleton)
- Weight: 6.7 kg
- silver
- Form factor: Micro-ATX, Mini-ITX, Mini-DTX
- Fan:
1x 120 mm (cover, 22 dB (A), 1,200 rpm)
2x 120 mm (bottom, 22 dB (A), 1,200 rpm)
1x 80 mm (cover, optional)
2x 80 mm (bottom, optional) - Drive bays:
1x 5.25 inches (external, slim, slot-in)
3x 3.5 inches (internal)
1x 2.5 inches (internal) - Power supply: standard ATX (optional)
- Expansion Slots: 4
- I / O panel:
2x USB 3.0 (external connection)
1x each audio in / out - Maximum graphic card
length : 347 mm Maximum CPU cooler height: 167 mm
Maximum network part length (fixed / modular): 180/160 mm - Insulation (pre-installed):
left side panel top
left side panel bottom
right side panel top
right panel bottom
front top
front bottom
panel cover (ventilation slot, clamped)
1x back - Insulation (enclosed):
bottom rear
cover (fan slot)
