Toote kirjeldus inglise keeles:
Noise is an annoying side effect that is caused not only at the airport by aircraft taking off and in traffic by passing trucks. Especially in your own home, therefore, many people strive to provide peace, to find relaxation. Unfortunately, the PC is in many cases contrary to these efforts and annoying during operation with high noise.
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Zalman Z11 Plus in black and orange, both approaches are connected and the housing is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
In the delivery state of the Zalman Z11 Plus, nine insulation mats are already glued or clamped. In addition, four mats are loosely in the housing, which are self-assembled as needed.
These mats are not installed so as not to restrict the ventilation of the system. Thus, an individual optimum of insulation (volume reduction) and ventilation (cooling) can be achieved. About the exact positions of the pre-glued, clamped or just enclosed mats give the specifications below information.
All additional insulation mats are labeled, which together with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Zalman Z11 Plus and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate.
Notes: Please note that due to the insulating mats, the space inside the housing may be smaller. Under certain circumstances, the laying of cables behind the mainboard tray in comparison to the uninsulated version can only be limited.
Technical details:
Noise is an annoying side effect that is caused not only at the airport by aircraft taking off and in traffic by passing trucks. Especially in your own home, therefore, many people strive to provide peace, to find relaxation. Unfortunately, the PC is in many cases contrary to these efforts and annoying during operation with high noise.
The sources of noise are initially all rotating components, which mainly affects fans and hard drives. These should be decoupled and, if necessary, the speed reduced. Many housings support these measures and already offer ex works equipment.
In addition, an insulation can provide even lower external noise. With this modified version of the Zalman Z11 Plus in black and orange, both approaches are connected and the housing is equipped with a pre-installed insulation.
The special feature of this compilation is that in addition to the pre-installed insulation mats additional insulation material included. This is also tailored to fit and allows additional sealing of other housing parts. As a result, you have the choice of how much insulation you use to achieve an individual optimum of cooling and volume reduction.
In the delivery state of the Zalman Z11 Plus, nine insulation mats are already glued or clamped. In addition, four mats are loosely in the housing, which are self-assembled as needed.
These mats are not installed so as not to restrict the ventilation of the system. Thus, an individual optimum of insulation (volume reduction) and ventilation (cooling) can be achieved. About the exact positions of the pre-glued, clamped or just enclosed mats give the specifications below information.
All additional insulation mats are labeled, which together with an enclosed installation manual ensures trouble-free installation. The manual is specially tailored to the requirements of the Zalman Z11 Plus and explains in detail the installation, gives practical tips and explains the possibilities and insulation options.
Function: The insulating mats achieve a noise reduction via two effects. First, the soft material absorbs airborne vibrations. At the same time, the mats reduce self-propagating vibrations via the housing, above all by their own weight. Both together ensure that the outer sides of the case are hardly stimulated to vibrate.
Notes: Please note that due to the insulating mats, the space inside the housing may be smaller. Under certain circumstances, the laying of cables behind the mainboard tray in comparison to the uninsulated version can only be limited.
Technical details:
- Dimensions: 260 x 498 x 525 mm (W x H x D)
- Material: steel
- Weight: 7.2 kg
- Color: Black
- Form factor: ATX, Micro-ATX
- Fan:
1x 120 mm (front, blue LED)
1x 120 mm (side panel, blue LED)
1x 120 mm (cover, blue LED)
1x 120 mm (rear)
1x 140 mm (front, optional instead of 120 mm)
2x 80 mm (side part)
2x 140/120 mm (cover, optional instead of 1x 120 mm)
1x 140/120 mm (bottom, optional)
Filter; Front, bottom - Drives:
4x 5.25 inches (external)
1x 3.5 + 1x 2.5 inches (external / internal)
5x 3.5 inches (internal)
1x 2.5 inches (internal) - Power supply (optional): Standard ATX
- Expansion Slots: 7
- I / O Panel:
2x USB 3.0 (externally connected)
2x USB 2.0
1x per Audio In / Out - Maximum graphics card length: 290 mm
- Insulation (pre-installed):
Left side panel top front
Left side panel bottom rear
right side panel top front
right side panel rear right
front floor - Insulation (clamped):
Lid in the back
Lid in the front
Back in the middle
Front - Insulation (enclosed):
Left side panel bottom left
Right side panel bottom front
Bottom center
Back top
