Tootekirjeldus inglise keeles:
CCA copper mixture for SOHO applications, AWG 24/1 (solid), PVC non-terminated data-/installationcable for proccessing and installation with LSA connection technology for Home/ indoor using double shielded twisted-pair LAN cable outer shield: braiding + foil screening Meets requirements for SOHO applications (Small Office, Home Office) up to a max. transmission length of 70 m! Technical specifications Performance Fire class (CPR) according to DIN EN 13501-6 Eca Cable Cable type round cable Specification CAT 5e Shielding class SF/UTP AWG 24/1 (solid) Meter scaling yes Cable sheath diameter (approx.) 5.7 mm Inner conductor material CCA (copper-clad aluminium) Material cable sheath PVC Cable length 100 m Number of shieldings 2 x Type 1, shielding foil (aluminium) Type 2, shielding braid (aluminium) Signal transmission max. bandwidth 100 MHz Impedance 100 Ω General Consumption Unit 1 pc. cable reel Color grey Markings ECA_CPR, SOHO, SOHO_70
CCA copper mixture for SOHO applications, AWG 24/1 (solid), PVC non-terminated data-/installationcable for proccessing and installation with LSA connection technology for Home/ indoor using double shielded twisted-pair LAN cable outer shield: braiding + foil screening Meets requirements for SOHO applications (Small Office, Home Office) up to a max. transmission length of 70 m! Technical specifications Performance Fire class (CPR) according to DIN EN 13501-6 Eca Cable Cable type round cable Specification CAT 5e Shielding class SF/UTP AWG 24/1 (solid) Meter scaling yes Cable sheath diameter (approx.) 5.7 mm Inner conductor material CCA (copper-clad aluminium) Material cable sheath PVC Cable length 100 m Number of shieldings 2 x Type 1, shielding foil (aluminium) Type 2, shielding braid (aluminium) Signal transmission max. bandwidth 100 MHz Impedance 100 Ω General Consumption Unit 1 pc. cable reel Color grey Markings ECA_CPR, SOHO, SOHO_70
